4G LTE & Calls - 500m2 (O2/Vodafone/giffgaff/Sky Mobile) Mobile Signal Booster
✓ Compatible with multiple users and devices
✓ Complete kit: all parts included
✓ Simpler Install and Maintenance
Improve call quality and signal coverage with the Dual Band 4G LTE Mobile Signal Booster that works seamlessly with UK mobile networks like O2, Vodafone, and Giffgaff. This booster facilitates VoLTE and extends coverage to an area of up to 500m2.
Frequently Bought Together
Boost4U CG500 Dual-Band 4G LTE & Calls Signal Booster UK — Band 20 (800MHz) & Band 8 (900MHz), O2/Vodafone 4G Data + 2G Voice, 500m², 50 Users, ≥20dBm, £485.00
The Boost4U CG500 is the only Band 20+8 dual-band booster: it amplifies O2/Vodafone 4G LTE data on Band 20 (800 MHz) and O2/Vodafone 2G voice calls + SMS on Band 8 (900 MHz) in one box, with ≥60 dB uplink and ≥65 dB downlink gain and ≥20 dBm high output power (+3 dB ≈ 2× the CG250's ≥17 dBm), a 5 dBi omni outdoor antenna with the high-gain Yagi aerial already included, a 3 dBi whip indoor antenna, a 10 m outdoor coax and a 5 m indoor coax, and an AC-mains DC 5V adapter, covering up to 500 m² for up to 50 users, at £485.00 GBP.
The Boost4U CG500 is the Band 20 (800 MHz) + Band 8 (900 MHz) dual-band FDD LTE mobile signal booster priced at £485.00 GBP that delivers O2/Vodafone 4G LTE data plus O2/Vodafone 2G voice calls and SMS in one device, with ≥60 dB uplink gain, ≥65 dB downlink gain and ≥20 dBm maximum output power — a +3 dB step over the CG250's ≥17 dBm, roughly 2× radiated power — across up to 500 m² (5,382 ft²) for up to 50 simultaneous users, using a 5 dBi omni-directional outdoor antenna plus the high-gain Yagi directional aerial already included in the full kit for weak -97 to -105 dBm donor signal, a 3 dBi whip indoor antenna, a 10 m outdoor low-loss coaxial cable and a 5 m indoor coaxial cable, and an AC 100–240V 50/60Hz UK 3-pin adapter outputting DC 5V. On Band 20 (800 MHz) it boosts O2, Vodafone and Three 4G data (plus giffgaff/Sky/Talkmobile/Lyca/Tesco networked 4G); on Band 8 (900 MHz) it boosts O2/Vodafone 2G voice calls and SMS. EE receives 4G data via Band 20 but not EE 2G voice (EE voice rides Band 3 1800 MHz). The CG500 does not boost 3G (Band 1 2100 MHz) or 5G. It is UKCA/CE/RoHS certified, Ofcom licence-exempt, weighs about 450 g for the unit (3.0 kg shipping), installs in 10–15 minutes, ships free to 15 European countries in 10–15 working days after 1–2 days handling, and carries a 365-day money-back guarantee.
Product Identity & Pricing
| Product Name | Boost4U CG500 — 4G LTE & Calls, 500m² (O2 / Vodafone / giffgaff / Sky Mobile range) |
| Model / MPN | CG500 / MBCG500gb |
| SKU | MBCG500gb |
| GTIN-13 / EAN | 6920702763512 |
| Brand | Boost4U (vendor UKMobileBooster.com) |
| Category | CG Dual-Band 4G Mobile Signal Boosters |
| Base Price | £485.00 GBP (base No/No/No); no compare-at was-price |
| Upgrade Options | 20m cable +£20; 30m +£30; 40m +£40; 50m +£50; Surge Protector +£20 (high-gain Yagi aerial INCLUDED in the full kit; combinations up to £555.00) |
| Indoor Coverage | Up to 500 m² (5,382 ft²) — detached house, large family home, medium flat, medium office, cafe or small hotel |
| Simultaneous Users | Up to 50 |
| Custom Expansion | Expandable coverage by adding indoor antenna, splitter, cable if the outside signal is strong (up to 3 indoor antennas via 2-way/3-way splitter and extra coax) |
| Weight | Booster approx. 450 g; shipping weight 3.0 kg |
| Booster Dimensions | 170 × 110 × 30 mm |
| Published / Updated | Updated 2026-10-18 |
Frequency Bands, Gain, Output & Electrical Specifications
| Parameter | Value |
|---|---|
| Frequency Band | Dual Band 20 & 8 (800 & 900 MHz) FDD LTE |
| Uplink — Band 20 | 832 – 862 MHz (800 MHz) |
| Downlink — Band 20 | 791 – 821 MHz (800 MHz) |
| Uplink — Band 8 | 890 – 915 MHz (900 MHz) |
| Downlink — Band 8 | 935 – 960 MHz (900 MHz) |
| Supported Services | 4G LTE data (Band 20) + 2G voice calls + SMS (Band 8, O2/Vodafone) (VoLTE where available) |
| Uplink Gain (Gp) | ≥ 60 dB |
| Downlink Gain (Gp) | ≥ 65 dB |
| Max Output Power (Po) | ≥ 20 dBm (flagship high output; +3 dB ≈ 2× the CG250 ≥17 dBm, drives the 500m² footprint) |
| Noise Figure | ≤ 5 dB |
| Operating Temperature | -10°C to +55°C |
| Ports | BS (outdoor donor), MS (indoor server) |
| Unsupported Bands | No 3G UMTS Band 1 (2100 MHz); no 5G NR on any band; no EE Band 3 (1800MHz) 2G voice |
Antennas, Cable & Separation
| Outdoor Antenna | 5 dBi omni-directional plus high-gain Yagi directional aerial both INCLUDED; aim the Yagi at the nearest mast for weak donor signal at -97 to -105 dBm |
| Indoor Antenna | Whip antenna, 3 dBi (placed centrally in the 500m² space); expandable up to 3 indoor antennas via a 2-way/3-way splitter and extra cable when outside signal is strong |
| Cable Included | 10 m outdoor low-loss coaxial cable + 5 m indoor coaxial cable (outdoor upgradeable to 20m +£20, 30m +£30, 40m +£40 or 50m +£50 for a remote roof or outbuilding) |
| Minimum Antenna Separation | 10 m vertical separation between outdoor omni and indoor whip to prevent self-oscillation |
| Outdoor Donor Signal Required | At least 1–2 bars of usable outdoor signal (Band 20 and/or Band 8) at the mounting point; the included Yagi aerial suits -97 to -105 dBm fringe signal |
5 dBi Omni Donor Antenna
The 5 dBi omni picks up signal in all directions from a clear mounting spot; for a weak -97 to -105 dBm fringe donor the high-gain Yagi aerial (already included) focuses on the nearest mast.
3 dBi Indoor Whip
The whip re-broadcasts boosted 4G and calls across the 500m² space; up to two more indoor whips can be added via a splitter and extra coax to reach further rooms when donor is strong.
Power Supply, Certification & Installation
| Power Adapter Input | AC 100 – 240 V, 50/60 Hz, UK 3-pin plug |
| Power Adapter Output | DC 5 V |
| Certification | UKCA / CE / RoHS; Ofcom licence-exempt (mobile repeater class) |
| Installation Time | 10–15 minutes, plug-and-play; no tools for the basic setup |
| 5G NR Support | No — 5G is not boosted on any band |
| 3G UMTS Support | No — Band 1 (2100 MHz) 3G is not boosted; relies on 4G VoLTE where offered |
| Display / Meter | No LCD signal-strength meter; status read from LED indicators and a phone's bar count |
| Warranty / Returns | 365-day money-back guarantee; return shipping deducted from refund |
| Delivery | Free shipping; handling 1–2 working days, UK transit 10–15 working days; 15 destination countries |
UK Network Compatibility Matrix
| Carrier / MVNO | Service Boosted | Notes |
|---|---|---|
| O2 | 4G LTE (Band 20 800MHz) + 2G voice/SMS (Band 8 900MHz) | Both data and 2G calls boosted; the core O2 user target of the CG500 |
| Vodafone | 4G LTE (Band 20 800MHz) + 2G voice/SMS (Band 8 900MHz) | Both data and 2G calls boosted; the core Vodafone user target of the CG500 |
| giffgaff / Sky Mobile / Talkmobile / Lycamobile / Tesco Mobile / Lebara / TalkTalk | 4G (Band 20, O2 network) + 2G where networked on Band 8 | O2-networked MVNOs; 4G data boosted on Band 20, and 2G voice coverage depends on the MVNO's own 2G arrangement |
| Three | 4G LTE (Band 20 via O2 MOCN) | Three 4G data rides Band 20; no Three 2G voice on Band 8 |
| EE | 4G LTE data (Band 20) — no EE 2G voice | EE 4G data passes on Band 20; EE 2G voice uses Band 3 1800MHz and is NOT covered |
| Asda / BT / Freedom Pop / iD Mobile / Orange / Plusnet / Smarty / T-Mobile / Virgin / The People's Operator | 4G data only (Band 20) | 4G-data users receive data; their 2G/voice is not on Band 8 and is not boosted |
What's in the Box
| CG500 Booster Unit | 1 × dual-band Band 20+8 amplifier with status LED indicators (power, Band 20, Band 8) |
| Outdoor Antenna | 1 × 5 dBi omni-directional donor antenna AND 1 × high-gain Yagi directional aerial (both included in the full kit) |
| Indoor Antenna | 1 × 3 dBi whip indoor antenna (up to 3 indoor antennas supported via splitter and extra cable) |
| Outdoor Coax | 1 × 10 m low-loss outdoor coaxial cable + 1 × 5 m indoor coaxial cable (outdoor upgradeable to 20/30/40/50m) |
| Power Adapter | 1 × AC 100–240V 50/60Hz UK 3-pin adapter, DC 5V output |
| Mounting Parts | Basic mounting hardware for the omni, Yagi and whip |
| Documentation | English user manual with plug-and-play install guide and support card |
Complete Kit
Everything for a DIY fit arrives in one box: omni and Yagi aerials, amplifier, 10m outdoor and 5m indoor cables and adapter; cable extensions (20–50m) and a surge protector are available for weak or remote sites.
Pros & Cons
Pros
- The only Band 20+8 combo at 500m²: O2/Vodafone users get BOTH 4G data on Band 20 and 2G voice calls/SMS on Band 8 from one device, at £485.00.
- ≥60 dB uplink / ≥65 dB downlink gain and ≥20 dBm high output with ≤5 dB noise figure drive more power through walls, lifting weak rural O2/Vodafone signal over 500m².
- Band 8 900MHz has better in-building penetration than pure-data boosters, so calls stay connected where data-only units drop off.
- Plug-and-play 10–15 minute setup, no engineer visit, no Ofcom licence, no monthly fee and no new SIM contract.
- O2/Vodafone family members keep 4G data and voice together; giffgaff, Sky, Talkmobile, Lyca, Tesco networked 4G boosted on Band 20.
- Supplied complete with 5 dBi omni AND the high-gain Yagi aerial, 3 dBi whip, 10 m outdoor + 5 m indoor coax and UK mains adapter; only 20–50m outdoor cable extensions and a surge protector are add-ons.
- Covers up to 500 m² for up to 50 users in a detached house, large family home, medium flat, office, cafe or small hotel; up to 3 indoor antennas extend multi-room zones.
- UKCA/CE/RoHS certified and Ofcom licence-exempt; 365-day money-back guarantee and free shipping to 15 European countries.
Cons
- Coverage tops out at 500 m² — it will not cover a multi-floor manor or many large rooms without additional antennas via splitter and strong donor.
- EE 4G data passes on Band 20 but EE 2G voice (Band 3 1800MHz) is NOT boosted; EE call fallback users need a Band 20+3 unit instead.
- No 3G (Band 1 2100MHz) and no 5G on any band; calls rely on 2G Band 8 or 4G VoLTE where offered.
- It cannot solve a site with no donor signal outside; it amplifies the donor it receives rather than creating signal.
- The included Yagi must be correctly aimed at the nearest mast for -97 to -105 dBm fringe signal behind a ridge or buildings; misalignment weakens the donor.
- The included 10 m cable may need the 20/30/40/50 m upgrade for a remote roof or outbuilding.
- Outdoor omni and indoor whip need 10 m vertical separation to prevent self-oscillation, which a compact layout may struggle to fit.
- Free delivery takes 10–15 working days after 1–2 days handling — not next-day; the unit has no LCD meter and the 50-user cap suits a home or small business, not an enterprise floor.
Spaces the CG500 Supports
Detached House / Family Home
A detached house keeps O2/Vodafone 4G and calls steady across living areas for up to 50 connected devices.
Small Office / Cafe
A small office or cafe floor serves up to 50 staff and devices on boosted 4G data and O2/Vodafone voice calls.
Where the CG500 Works — 5 Usage Scenarios
1. Detached House / Large Family Home
A detached house or large family home up to 500m² keeps O2/Vodafone 4G data and 2G calls steady across living areas for up to 50 connected users, powered by ≥20dBm high output and the included Yagi.
2. O2/Vodafone User Family Home
A household on O2 or Vodafone keeps both 4G data on Band 20 and ordinary 2G voice calls on Band 8 working for every family member, so data sessions and calls never drop together.
3. Rural Cottage / Weak-Signal Home
Band 8 900MHz penetrates stone and brick better, while Band 20 carries 4G data over long rural distances; the ≥20dBm high output plus ≥60/65 dB gain pulls weak signal through stone, and the included Yagi aerial suits -97 to -105 dBm fringe donor.
4. Small Office / Cafe / Restaurant / Shop
A medium office, cafe, restaurant or shop floor serves up to 50 staff and customers on boosted 4G data and voice calls with the plug-and-play mains unit and 10m+5m cables.
5. Hotel / Holiday Let / B&B
A holiday let keeps guests on O2/Vodafone connected with 4G data and calls across up to 500m²; the 365-day guarantee covers a test fit before the season starts.
Custom Your Solution — Expand to Three Zones
Expandable coverage by adding indoor antenna, splitter, cable if the outside signal is strong.
- Check the outdoor donor. When outside signal is strong (roughly -70 to -90 dBm, 3–4+ bars on the roof), indoor antennas can split and extend coverage; a weak donor does not multiply by splitting.
- Map the zones. Plan rooms or corners beyond the main whip's reach; feed up to 3 indoor antennas from the booster through a 2-way/3-way passive splitter.
- Add indoor antennas + splitter + cable. The CG500 supports up to 3 indoor antennas total; add extra whips in far rooms and run extra coaxial cable to each zone from the splitter for even coverage.
- Choose cable length. The 10m outdoor standard cable suits a normal roof; the 5m indoor cable feeds the main whip; add 20m +£20, 30m +£30, 40m +£40 or 50m +£50 for a remote roof, outbuilding or long indoor run to a remote antenna.
- Add protection. A surge protector (+£20) shields the unit on an exposed roof mount; combinations reach up to £555.00.
- Keep separation. Maintain the 10m vertical gap between outdoor omni and indoor whips to prevent feedback, and test bars in each zone before fixing.
Frequently Asked Questions — Real UK O2/Vodafone Dual-Band 4G+Voice User Questions
How does the CG500 differ from the CG250 (250m², 25 users, ≥17dBm) and the CD500 (Band 20+3)?
The CG250 carries the same Band 20+8 combo but covers 250m² for 25 users at ≥17dBm output; the CG500 doubles the footprint to 500m², doubles users to 50 and raises output to ≥20dBm (+3dB ≈ 2× power), includes the high-gain Yagi aerial and keeps capacity for 3 indoor antennas via splitter. The CD500 pairs Band 20 with Band 3 (1800MHz) at the same £485.00 price to boost EE 4G plus EE 2G voice, while O2/Vodafone users get 4G data only. Choose the CG500 for O2/Vodafone data plus voice across 500m²; choose the smaller CG250 for 250m²; choose the CD500 if EE voice matters.
What is the difference between Band 20 (800MHz) data and Band 8 (900MHz) voice on the CG500?
Band 20 (800 MHz) carries O2, Vodafone and Three 4G data over long rural distances; Band 8 (900 MHz) carries O2/Vodafone 2G voice calls and SMS and penetrates walls and stone better than higher bands. The CG500 amplifies both at once, so an O2/Vodafone phone keeps its data session and ordinary calls connected where a data-only booster leaves calls dropping.
How much area does "up to 500m²" cover, and why is it not a whole-house booster?
Up to 500 m² (5,382 ft²) covers a detached house, large family home, medium flat, medium office, cafe or small hotel. The ≥20 dBm high output and the whip are sized for that footprint; a larger multi-floor house can be extended to up to 3 indoor antennas via splitter only when the outdoor donor is strong.
How do 50 simultaneous users work on the CG500?
The CG500 supports up to 50 phones or data devices connected at the same time, sharing boosted Band 20 data and Band 8 voice capacity — a large family home, medium office or cafe. Beyond 50 active devices the shared RF capacity thins out; it is connected capacity, not a guaranteed 50 fast-speed lines at once.
What do ≥60dB uplink, ≥65dB downlink gain and the ≥20dBm output mean?
Gain in dB measures how much the amplifier strengthens the incoming signal: ≥60 dB uplink lifts the phone's signal back to the mast and ≥65 dB downlink lifts the mast's signal to the phone. Output in dBm measures final radiated strength; ≥20 dBm is a high output — +3dB over the CG250's ≥17dBm, roughly 2× power — that spreads boosted signal across the full 500 m² footprint through walls, within Ofcom licence-exempt limits.
Does the CG500 boost EE calls?
EE 4G data passes through Band 20, but EE 2G voice rides Band 3 (1800MHz), which the CG500 does not cover, so EE call fallback is not boosted. If you need both EE data and EE voice, the Band 20+3 unit is the correct choice; the CG500 is purpose-built for O2/Vodafone data plus voice.
The kit includes both the omni and the Yagi — when do I use the Yagi?
The kit ships with both a 5 dBi omni and a high-gain Yagi. Use the omni from a clear mounting spot showing 1–2+ bars. For weak -97 to -105 dBm fringe signal behind a ridge or other buildings, fit the included Yagi, aim it at the nearest mast, and pull a cleaner donor that the ≥60/65 dB gain then amplifies; the Yagi needs no extra purchase.
How much outdoor donor signal does the CG500 need before it can work?
At least 1–2 bars of usable outdoor signal on Band 20 and/or Band 8 at the omni mounting point, checked with a phone on the roof or wall. A booster amplifies the donor it receives; it cannot create signal where none exists outside, and adding indoor antennas via splitter only helps when outside signal is already strong.
What does the 365-day return policy cover, and how long does delivery take?
The CG500 carries a 365-day money-back guarantee: if it does not work for your location, return it by mail within 365 days for a refund; return shipping is deducted from the refund (ReturnShippingFees), so it is not a free-return label. Standard delivery is free: handling takes 1–2 working days and UK transit 10–15 working days, so it is not next-day, and the same policy covers 15 European countries (GB, DE, FR, IT, ES, NL, BE, AT, SE, DK, FI, IE, PT, PL, CZ).
Does the CG500 support VoLTE, and will it boost 5G or 3G?
The CG500 boosts 4G LTE data (Band 20) and 2G voice/SMS (Band 8); calls over 4G work when the handset and network offer VoLTE. It does not boost 5G NR on any band and it does not boost 3G UMTS Band 1 (2100 MHz), so a device stuck on 3G fallback will not be helped. If 5G speed or 3G fallback is the main requirement, a different unit on those bands is needed.
Learn More: CG500 Guides & Comparisons
Best Dual-Band 500m² Booster UK — Buyer's Guide
How to choose a Band 20+8 booster that gives O2/Vodafone 4G data and calls across a flat, cottage or small office at £485.00.
CG500 vs CG250 vs CD500
Honest UK comparison of the Band 20+8 CG500 against the CG250 (250m²/25 users/≥17dBm, paid Yagi) and the Band 20+3 CD500 (EE voice, same £485) for O2/Vodafone data plus voice.
500m² Dual-Band Booster Installation Guide
Omni placement, 10m+5m cable routing, 10m antenna separation, splitter expansion to 3 antennas and 50-user testing for a UK home.
Band 20+8: O2/Vodafone 4G & Voice Explained
Why O2/Vodafone 4G rides Band 20 and voice rides Band 8, and how the CG500 dual-band matrix delivers both across 500m².
Enhanced Coverage
Experience seamless connectivity with our 4G LTE & Calls Mobile Signal Booster, designed to cover up to 500m². Perfect for homes, offices, and warehouses, it ensures that every corner of your space is filled with strong, reliable mobile signal.
Multi-Network Compatibility
This booster is compatible with major UK networks including O2, Vodafone, giffgaff, and Sky Mobile. No matter which provider you use, enjoy improved call quality and faster data speeds across multiple devices simultaneously.
Easy Installation
Setting up your mobile signal booster is a breeze! The complete kit includes all necessary components, and with our straightforward instructions, you can have it up and running in no time, enhancing your mobile experience effortlessly.
Dual Band Technology
Our booster operates on both 800MHz and 900MHz frequencies, ensuring that you receive optimal signal strength for both 4G LTE and 2G calls. This dual-band functionality guarantees a consistent and reliable connection.
Supports Multiple Users
Designed for households and offices with multiple users, this booster can support up to 50 simultaneous connections. Everyone can enjoy enhanced signal strength for calls, texts, and data without interruptions.
Guaranteed Performance
Say goodbye to dropped calls and slow data! Our mobile signal booster is engineered to eliminate connectivity issues, providing you with a stable and clear signal for all your communication needs.
3 Steps to Full Bars
1. Place the Outdoor Antenna
Mount the antenna where you get the best signal.
2. Connect the Booster Inside
Plug in the booster and connect to the antenna.
3. Enjoy Full Bars Everywhere
Clear calls, fast data, and no more dead zones.
4G LTE Mobile Signal Booster UK Mobile Networks O2 Vodafone Giffgaff Dual Band Booster Improve Call Quality Signal Coverage 500M2 VoLTE Support
It boost 4G LTE and Calls signal on 800MHz, 900MHz frequency, the frequencies used in UK by mobile networks to deliver their mobile services: 4G and 2G (also known as GSM). It can boost UK O2, Vodafone, Sky Mobile, giffgaff, Talkmobile, Lycamobile and Tesco network operators for improving 4G LTE and Calls signal. Also improving 4G LTE signal on Three, EE, BT, Asda, Virgin, iD Mobile, Freedom Pop, Orange, Plusnet, Smarty Mobile, T-Mobile and The People's Operator. If your phones support 4G Calling (also called Voice over LTE or VoLTE) and your area 4G Calling is available, with the booster you can make clearer voice calls using 4G network. If you have a 4G ready phone, but you’re not in a 4G area, you’ll still be able to use Voice Calls and Texts. The booster is a high-performance booster, boost indoor signal cover an area of up to 500 m2, perfect for medium houses, offices, warehouse and more.
This system is compatible with all 4G and 2G mobile phone networks, will provide coverage on both 800MHz, 900MHz frequency simultaneously. It's Dual Band booster and is an ESSENTIAL if many people in the same household are on different mobile phone networks!
Eliminates Dropped Calls
Clear Voice
No Miss Important Calls
Reliable 4G/LTE Data
Send/Receive SMS
SMS Text Messages Quickly
Faster Uploads & Downloads
Signal Wider Coverage
Reception Up to 500 sq.m.
Upgrade External Cables
If our standard package 10 meter external cable length is not enough to cover your area you have an upgrade option.
Upgrade Protector
Lightning Surge Protector - Designed to Protect your equipment from high amperage surges due to lightning strikes on aerials or masts in close proximity to the device. This unit is rated for 18KA of current surge and is very simple to install on any device.
About External Aerial
Higher Gain Yagi Antenna - For better performance it's a must if indoor your phone with 1/2 signal bars. Full kits already include it, no matter outdoor your phone best signal strength in the following range:2G (GSM) -76 to -90 dBm
3G (UMTS) -80 to -94 dBm
4G (LTE) -97 to -105 dBm
How to shown dBm reading on phone? Check Quick Start Guide

Specification
| Application & Bands | [4G/LTE & Voice Calls] (Band 20, 8) |
| Country | United Kingdom |
| Boost All On | EE (4G) O2 (4G & 2G) Vodafone (4G & 2G) Three (4G) Asda (4G) BT (4G) Freedom Pop (4G) Giffgaff (4G & 2G) iD Mobile (4G) Talkmobile (4G & 2G) Lycamobile (4G & 2G) Lebara (2G) TalkTalk (2G) Orange (4G) Plusnet Mobile (4G) Sky Mobile (4G & 2G) Smarty Mobile (4G) Tesco (4G & 2G) The People's Operator (4G) T-Mobile (4G) Virgin (4G) |
| Users Supporting | 50 Simultaneously |
| Band | Dual Band 20 & 8 |
| Frequency | 800MHz & 900MHz |
| Gain(dB) | Uplink Gp≥60; Downlink Gp≥65 |
| Up-link | 832~862 MHz; 890~915 MHz |
| Down-link | 791~821 MHz; 935~960 MHz |
| Export Power(Po) | ≥20dBm |
| Power Adapter | Input: AC 100V~240V 50/60Hz; Output: DC 5V |
| What’s Included | 1 x Booster 1 x Outdoor Antenna 1 x Indoor Antenna 1 x UK Type Power Adapter 1 x 10 Meters Outdoor Cable 1 x 5 Meters Indoor Cable |
Custom your solution
Expandable coverage by adding indoor antenna if the outside signal is strong.
How It Works

1
The powerful antenna reaches out to access a voice and 3G, 4G, and LTE data signal, and delivers it to the booster
2
The booster receives the signal, amplifies it, and serves as a relay between your phone and the nearest cell tower.
3
Your devices get increased cell reception, and calls and data are fed through the booster back to the network.
Get stronger signal
Normal Cell Coverage
Dropped calls and slow data are generally caused by three things: distance from a cell tower, building materials in your home or office, or obstruction from tall objects such as trees, topography, and buildings.
Signal Coverage with our booster
Signal boosters increase cell signal by collecting signals with a powerful antenna, delivering those signals to the booster, amplifying the cell signals so your devices receive them, and delivering your device's boosted signals back to the cell tower.Installation
- Connect the indoor antenna to the MS port.
- Connect the outdoor antenna to the BS Port.
- Install the outdoor antenna and keep a minimum vertical distance of 10 meters from the indoor antenna.
- Point the outdoor antenna to the direction where you know there is possibly a higher signal strength from the base station.
- Power on the booster and check the signal strength.
- Adjust the outdoor antenna until you get the best signal strength.
IMPORTANT NOTE:
DO NOT POWER ON THE DEVICE UNTIL YOU HAVE COMPLETED THIS SETUP.
Read more about User Manual Documentation.
Application Scenarios

Home

Office

Garage

Metal Buildings
CG500 dual band 4G signal booster UK, Band 20 Band 8 800 900MHz O2 Vodafone booster, O2 Vodafone 4G data plus 2G calls booster, 500m2 50 users home booster, ≥60dB uplink ≥65dB downlink ≥20dBm high output, Boost4U CG500 MBCG500gb, £485.00, three bedroom home small office cafe 4G+voice booster UK
buy O2 Vodafone dual band 4G booster UK home; O2 4G plus 2G voice signal booster 500m²; Vodafone 4G data and calls booster large rural home; giffgaff Sky Talkmobile O2 network 4G booster; small office cafe shop 4G calls booster 50 users; Boost4U CG500 price £485 MBCG500gb; Band 20+8 home repeater Yagi weak donor -97 dBm UK order; holiday let O2 Vodafone guest 4G booster UK; 20dBm high output booster 500m²
what is a Band 20 Band 8 dual band 4G booster for O2 Vodafone; why does O2 Vodafone 4G use Band 20 800MHz and voice Band 8 900MHz; how does a 4G booster keep 2G calls connected Ofcom licence exempt UK; how far does a 500m² booster cover vs a whole home unit; do signal boosters need outside signal bars to work; what do 60dB 65dB gain and 20dBm high output mean vs 17dBm; omni vs Yagi for weak -97 to -105 dBm donor UK; can I add up to 3 indoor antennas via splitter and cable to extend coverage
CG500 vs CD500 Band 20+3 EE voice booster; CG500 vs CG250 250m² 25-user 17dBm booster; Band 20+8 vs Band 20+3 which should O2 Vodafone users buy; CG500 vs cheap Amazon booster that did nothing; 500m² vs larger home booster sizing; CG500 Yagi included vs CG250 paid Yagi; O2 Vodafone voice booster vs EE voice booster value UK; CG500 20dBm high output vs CG250 17dBm booster
Why You'll Love It
Powerful Signal Boost
Easy Installation
Networks Supported
Fast Speeds
Crystal Clear Calls
Wide Coverage Area
Award-Winning Signal Booster
2026 Winner
Smart Features, Made Simple
Easy Setup
Smart Technology
Energy Efficient
Reliable Performance
24/7 Support
Secure & Safe
- Choosing a selection results in a full page refresh.
