3G Data & Calls - 200m2 (EE/ASDA/BT) Mobile Signal Booster
✓ Compatible with multiple users and devices
✓ Complete kit: all parts included
✓ Simpler Install and Maintenance
Enhance the quality of voice calls on UK mobile networks with our range of signal boosters, including the 3G Mobile Signal Booster, EE Signal Booster, ASDA Mobile Booster, BT Mobile Signal Enhancement, and Indoor Coverage Booster. Experience improved indoor coverage and enhanced signal strength with our dual-band signal boosters. Choose our mobile network solutions to elevate your communication experience.
Frequently Bought Together
Boost4U DW200 EE Family Voice+4G & 3G All-Networks Booster UK — Band 3 (1800MHz) + Band 1 (2100MHz), EE/BT/ASDA/Virgin Calls + 3G for O2/Vodafone/Three, 200m², 20 Users, £205.99
The Boost4U DW200 is the 200m² model of the DW Band 3+1 dual-band booster: on Band 3 (1800 MHz) it amplifies EE-family voice calls and 4G LTE for EE, BT, ASDA and Virgin, and on Band 1 (2100 MHz) it amplifies 3G UMTS data, calls and SMS for all four networks — EE, O2, Vodafone and Three, with ≥60 dB uplink and ≥65 dB downlink gain, ≥10 dBm output, a 5 dBi omni outdoor antenna (high-gain Yagi as a paid upgrade), a 3 dBi whip indoor antenna, a 10 m outdoor coax plus a 5 m indoor coax and an AC 100–240V to DC 5V UK adapter, covering up to 200 m² for up to 20 users, at £205.99 GBP.
The Boost4U DW200 is the Band 3 (1800 MHz) + Band 1 (2100 MHz) dual-band FDD mobile signal booster priced at £205.99 GBP that delivers EE-family voice calls and 1800MHz 4G LTE on Band 3 plus 3G UMTS data, voice calls and SMS on Band 1 across EE, O2, Vodafone and Three from one device, with ≥60 dB uplink gain, ≥65 dB downlink gain and ≥10 dBm maximum output power, across up to 200 m² (two-bed flat / small house) for up to 20 simultaneous users. It uses a 5 dBi omni-directional outdoor antenna (high-gain Yagi directional aerial available as an upgrade for weak donor), a 3 dBi whip indoor antenna, a 10 m outdoor low-loss coaxial cable plus a 5 m indoor cable (outdoor cable upgradeable to 20/30/40/50m) and an AC 100–240V 50/60Hz UK Type plug feeding DC 5V. On Band 3 (1800MHz) it boosts EE, BT, ASDA, Virgin, Orange, T-Mobile and TPO voice calls and 4G LTE; on Band 1 (2100MHz) it boosts 3G UMTS data, calls and SMS for EE, O2, Vodafone, Three and their networked MVNOs. The DW200 does not boost Band 20 (800MHz) rural 4G, does not boost Band 8 (900MHz) 2G voice and does not boost 5G; non-EE-family calls on O2/Vodafone/Three run over boosted 3G Band 1 or 4G VoLTE where available. It is UKCA/CE/RoHS certified, Ofcom licence-exempt, installs plug-and-play in 10–15 minutes with no tools, ships free to 15 European countries in 10–15 working days after 1–2 days handling, and carries a 365-day money-back guarantee. Upgrade options: high-gain Yagi aerial, 20/30/40/50m outdoor cable, 18KA surge protector.
Product Identity & Pricing
| Product Name | Boost4U DW200 — EE Family Voice+4G & 3G All-Networks, 200m² (EE/BT/ASDA/Virgin + EE/O2/Vodafone/Three 3G) Mobile Signal Booster |
| Model / MPN | DW200 / MBDW200gb |
| SKU | MBDW200gb |
| GTIN-13 / EAN | 6920702763512 |
| Brand | Boost4U (vendor UKMobileBooster.com) |
| Category | DW Dual-Band Voice/3G/4G Mobile Signal Boosters |
| Base Price | £205.99 GBP (standard omni-kit) |
| Upgrade Options | High-gain Yagi directional aerial (weak rural donor); outdoor cable 20M/30M/40M/50M; 18KA lightning surge protector |
| Indoor Coverage | Up to 200 m² (2,153 ft²) — two-bed flat / small house |
| Simultaneous Users | Up to 20 |
| Shipping Weight | 3.0 kg |
| Installation | Plug-and-play, 10–15 minutes, no tools; minimum 10 m vertical separation between outdoor and indoor antennas |
| Published / Updated | Updated 2026-10-25 |
Frequency Bands, Gain, Output & Electrical Specifications
| Parameter | Value (compact spec table — authoritative) |
|---|---|
| Frequency Band | Dual Band 3 & 1 (1800 & 2100 MHz) FDD — Band 3+1 ONLY (no Band 20, no Band 8) |
| Uplink — Band 3 | 1710 – 1785 MHz (1800 MHz) |
| Downlink — Band 3 | 1805 – 1880 MHz (1800 MHz) |
| Uplink — Band 1 | 1930 – 1990 MHz (2100 MHz 3G) |
| Downlink — Band 1 | 2110 – 2180 MHz (2100 MHz 3G) |
| Supported Services | Band 3: EE-family voice calls + 4G LTE (EE/BT/ASDA/Virgin/Orange/T-Mobile/TPO); Band 1: 3G UMTS data / voice calls / SMS for EE/O2/Vodafone/Three; VoLTE where available |
| Uplink Gain (Gp) | ≥ 60 dB |
| Downlink Gain (Gp) | ≥ 65 dB |
| Max Output Power (Po) | ≥ 10 dBm per band (Ofcom licence-exempt) |
| Noise Figure | ≤ 5 dB |
| Operating Temperature | -10°C to +55°C |
| Ports | BS (outdoor donor antenna), MS (indoor server whip) |
| Unsupported Bands | No Band 20 (800MHz) rural 4G; no Band 8 (900MHz) 2G voice; no Band 20/3 combination; no 5G NR on any band |
Antennas, Cable & Mounting
| Outdoor Antenna | 5 dBi omni-directional antenna included in the standard £205.99 kit; upgrade to a high-gain Yagi directional aerial for weak fringe donor behind hills |
| Indoor Antenna | Whip antenna, 3 dBi, placed indoors to re-broadcast boosted Band 3 voice/4G and Band 1 3G; expandable to up to 2 indoor antennas via a 2-way splitter |
| Cable Included | 10 m outdoor low-loss coaxial cable + 5 m indoor coaxial cable; outdoor cable upgrade options 20M / 30M / 40M / 50M for a remote roof or long run |
| Mounting | Outdoor omni on a clear roof/wall spot aimed toward the best base station; indoor whip in the covered room; plug-and-play, no tools; keep ≥10 m vertical separation between antennas |
| Outdoor Donor Signal Required | At least 1–2 bars of usable outdoor Band 3 / Band 1 signal at the antenna point; the Yagi upgrade focuses on the nearest mast for fringe signal |
5 dBi Omni Outdoor Antenna (Standard Kit)
The 5 dBi omni picks up Band 3 and Band 1 in all directions from a clear mounting spot; the paid Yagi upgrade aims at the nearest mast for weak rural donor behind hills.
3 dBi Indoor Whip Antenna
The whip re-broadcasts Band 3 calls/4G and Band 1 3G across the flat or small house; a second whip via a 2-way splitter covers a far room or upstairs area when the outdoor donor is strong.
Power Supply, Certification & Installation
| Power Adapter | Input AC 100V–240V 50/60Hz (UK Type plug); output DC 5V |
| Certification | UKCA / CE / RoHS; Ofcom licence-exempt (mobile repeater class) |
| Installation Time | 10–15 minutes, plug-and-play, no tools; do not power on until setup is complete |
| 5G NR Support | No — 5G is not boosted on any band |
| Band 20 / Band 8 Support | No Band 20 (800MHz) rural 4G and no Band 8 (900MHz) 2G voice; calls run over Band 1 3G or 4G VoLTE |
| Warranty / Returns | 365-day money-back guarantee; lifetime technical support; return shipping deducted from refund |
| Delivery | Free shipping; handling 1–2 working days, UK transit 10–15 working days; 15 destination countries |
UK Network Compatibility Matrix
| Carrier / MVNO | Service Boosted | Notes |
|---|---|---|
| EE | Band 3 voice calls + 4G LTE + Band 1 3G calls/data | Core EE-family target: voice and 1800 4G on Band 3, all-network 3G on Band 1 |
| BT / ASDA Mobile / Virgin / Orange / T-Mobile / TPO | Band 3 EE-networked voice calls + 4G LTE + Band 1 3G | EE-networked MVNOs; voice and 4G ride Band 3 on the EE network; 3G fallback on Band 1 |
| O2 | Band 1 3G UMTS calls/data/SMS only | No O2 voice band and no O2 Band 20 4G in the DW200; calls over 3G or VoLTE where offered |
| Vodafone | Band 1 3G UMTS calls/data/SMS only | No Vodafone voice band and no Vodafone Band 20 4G in the DW200; calls over 3G or VoLTE where offered |
| Three | Band 1 3G UMTS calls/data/SMS only | No Three Band 20 4G in the DW200; data and calls over boosted 3G Band 1 |
| Freedom Pop / giffgaff / iD Mobile / Lebara / Lycamobile / Plusnet / Sky Mobile / Smarty / Talkmobile / TalkTalk / Tesco Mobile | 3G Band 1 only (per host network) | 3G calls and data boosted on Band 1; no Band 3 voice unless networked on EE |
What's in the Box
| DW200 Booster Unit | 1 × dual-band Band 3+1 amplifier with status LED indicators |
| Outdoor Antenna | 1 × 5 dBi omni-directional donor antenna (high-gain Yagi is a paid upgrade, not in this box) |
| Indoor Antenna | 1 × 3 dBi whip indoor antenna |
| Cable | 1 × 10 m outdoor low-loss coax + 1 × 5 m indoor coax (20/30/40/50m outdoor upgrade optional) |
| Power Adapter | 1 × AC 100–240V UK Type plug adapter outputting DC 5V |
| Documentation | English user manual with plug-and-play install guide and support card |
Complete Kit
Everything for a DIY fit arrives in one box: omni, amplifier, whip, 10m outdoor coax, 5m indoor coax and UK DC5V adapter; Yagi aerial, longer outdoor cable and surge protector are optional add-ons.
Pros & Cons
Pros
- Band 3+1 combo for the 200m² tier at £205.99: EE-family voice calls and 1800MHz 4G LTE on Band 3 for EE, BT, ASDA and Virgin, plus all-network 3G UMTS on Band 1 for EE, O2, Vodafone and Three from one box — the DW200 position the CD200 and CW200 cannot match for EE voice.
- ≥60 dB uplink / ≥65 dB downlink gain (15 dB more than the DW100) spreads boosted Band 3 voice/4G and Band 1 3G across two bedrooms or a small house for up to 20 devices.
- Reliable EE-family voice calls hold where a 4G-only unit drops them, while Band 1 3G keeps O2/Vodafone/Three members connected as a fallback.
- 5 dBi omni standard; high-gain Yagi upgrade for weak fringe donor; 10m outdoor cable plus 5m indoor cable in the box; outdoor cable upgradeable to 20/30/40/50m; 18KA surge protector available.
- AC 100–240V to DC 5V UK adapter, UKCA/CE/RoHS, Ofcom licence-exempt, plug-and-play in 10–15 minutes with no tools.
- Expandable to up to 2 indoor antennas via a 2-way splitter and extra cable when the outdoor donor is strong.
- 365-day money-back guarantee, lifetime technical support and free shipping to 15 European countries (handling 1–2 days, transit 10–15 days).
Cons
- No Band 20 (800MHz) rural 4G for O2/Vodafone/Three; those networks get Band 1 3G only, not 4G data.
- No Band 8 (900MHz) O2/Vodafone 2G voice; non-EE-family calls run over boosted 3G Band 1 or 4G VoLTE where offered.
- Coverage is 200m² (two-bed flat / small house), not a three-bedroom detached house or multi-storey property; far rooms weaken.
- No 5G NR on any band.
- It cannot solve a location with no donor outside; it amplifies the signal it receives rather than creating signal.
- Yagi aerial, long outdoor cable and surge protector are paid add-ons.
- Up to 20 connected devices; beyond that shared RF capacity thins out.
- Free delivery takes 10–15 working days after 1–2 days handling — not next-day; splitter expansion only helps with a strong outdoor donor.
Where the DW200 Helps
Steady EE Voice + 4G and 3G Bars
Band 3 keeps EE-family calls and 1800 4G up, while Band 1 keeps 3G for everyone as a fallback, so bars stay up where a 4G-only unit would drop across two floors.
Plug-and-Play Install
Mount the omni outside, place the whip inside, run the 10m outdoor and 5m indoor cables and plug the DC5V adapter in — done in 10–15 minutes, no tools, ≥10 m antenna separation.
Where the DW200 Works — 5 Scenarios
1. Two-Bed Flat / Small House
The 200m² footprint fits a two-bedroom flat or a small terraced/semi house; the whip covers living room, kitchen and bedrooms, and up to 20 residents keep EE-family calls and 4G plus Band 1 3G connected on EE, O2, Vodafone or Three.
2. EE-Household Family (EE + BT/ASDA/Virgin)
A family on EE, BT, ASDA or Virgin gets Band 3 voice calls, text and 1800 4G around the home; where the 4G is weak, boosted Band 1 3G keeps everyday calls and messages going on the same EE-networked SIMs.
3. Rural Weak-Signal Cottage / Terraced Home
In a Devon or Wales cottage with only 1–2 bars, the optional Yagi aerial focuses on the nearest mast and the 20–50m outdoor cable upgrade reaches a remote roof; Band 3 keeps EE-family calls alive and Band 1 3G provides the fallback off the 4G map.
4. Small Office / Home Office / Small Shop / Salon
Up to 20 staff or devices share boosted Band 3 calls/4G and Band 1 3G for video calls, till and PIN coverage; the 2-antenna split can reach a back office, treatment room or storeroom when the donor outside is strong.
5. Garage / Metal Building / Workshop
Metal sheets block signal; the omni sits outside on the 10m outdoor cable and the whip inside pulls Band 3 calls/4G and Band 1 3G through, keeping a workshop, garage conversion or metal store connected for phones and machine monitoring; a second whip via splitter extends the zone.
Custom Your Solution — Expand to Two Zones
Expandable coverage by adding indoor antenna, splitter, cable if the outside signal is strong.
- Check the outdoor donor. When outside signal is strong (roughly -70 to -90 dBm, 3–4+ bars on the roof), a second indoor antenna can split and extend coverage; a weak donor does not multiply by splitting.
- Map the two zones. Identify the main area covered by the whip and a second far room, upstairs bedroom, back office, treatment room or garage beyond reach; feed up to 2 indoor antennas total from the booster through a 2-way passive splitter.
- Add indoor antenna + splitter + cable. Add a second whip and run extra coaxial cable from the 2-way splitter to it for even coverage across two zones; remember splitting reduces power per branch, so keep both antennas close enough to the booster.
- Choose cable length. The 10m outdoor plus 5m indoor cable suits a normal roof; add 20/30/40/50m outdoor cable for a remote roof or a long run to the second antenna.
- Add protection. A 18KA surge protector shields the unit on an exposed roof or mast mount; Yagi, cable and protector are optional paid upgrades.
- Keep separation. Maintain the ≥10 m gap between outdoor omni and indoor whips to prevent feedback, and test EE-family calls and 3G bars in both zones before fixing.
Frequently Asked Questions — Real UK Band 3+1 EE Voice+4G & 3G User Questions
How does the DW200 differ from the DW100, CD200 and CW200 at the same 200m² tier?
The DW200 is the Band 3+1 combo for the 200m² tier: Band 3 (1800MHz) carries EE-family voice calls and 4G LTE for EE, BT, ASDA and Virgin, while Band 1 (2100MHz) carries 3G UMTS data, calls and SMS for EE, O2, Vodafone and Three. The DW100 is the same Band 3+1 combo at £185.99 but for 100m², 10 users and ≥45/50dB gain; the CD200 (Band 20+3, 800+1800) gives EE/O2/Vodafone 4G data but no 3G and no voice band; the CW200 (Band 20+1, 800+2100) gives O2/Vodafone 4G data plus all-network 3G but no EE voice. Choose the DW200 for an EE-family household needing reliable voice calls plus 4G and an all-network 3G fallback across two bedrooms or a small house.
What is the difference between Band 3 (1800MHz) EE voice+4G and Band 1 (2100MHz) 3G on the DW200?
Band 3 (1800 MHz) is the EE-family band: it boosts EE, BT, ASDA, Virgin, Orange, T-Mobile and TPO voice calls and text plus 1800MHz 4G LTE data. Band 1 (2100 MHz) is the all-network 3G band: it boosts 3G UMTS data, voice calls and SMS for EE, O2, Vodafone and Three and their networked MVNOs, acting as the fallback when 4G drops or when an O2/Vodafone/Three phone has no Band 3 coverage. The DW200 amplifies both at once, so EE-family calls hold up and everyone else still gets boosted 3G across the 200m² footprint.
How much does “up to 200m²” cover, and what does it fit?
Up to 200 m² (2,153 ft²) covers a two-bedroom flat, a small terraced or semi house, a rural cottage, a small office/home office/shop/salon, or a garage or metal workshop on the same property. The whip re-broadcasts boosted Band 3 voice/4G and Band 1 3G around that footprint; a larger three-bedroom detached house or multi-storey property needs a bigger model.
How do 20 simultaneous users work on the DW200?
The DW200 supports up to 20 phones or data devices connected at the same time, sharing boosted Band 3 voice/4G and Band 1 3G capacity across a two-bed flat, small family home, home office or small shop. Beyond 20 active devices the shared RF capacity thins out; it is connected capacity, not a guaranteed 20 separate high-speed lines at once.
What do 60dB uplink, 65dB downlink gain and the ≥10dBm output mean on the DW200?
Gain in dB measures how much the amplifier strengthens the incoming signal: 60 dB uplink lifts the phone's signal back to the mast and 65 dB downlink lifts the mast's signal to the phone — 15 dB more gain than the DW100's ≥45/50dB, which is what spreads boosted signal across 200m² rather than a single room. Output in dBm measures final radiated strength; ≥10 dBm spreads boosted Band 3 voice/4G and Band 1 3G around the home within Ofcom licence-exempt limits for a mobile repeater.
Which voice calls does the DW200 boost — do O2, Vodafone and Three calls work?
Band 3 (1800MHz) voice calls are boosted for the EE family: EE, BT, ASDA, Virgin, Orange, T-Mobile and TPO. O2, Vodafone and Three do not have a voice band in the DW200; their calls run over boosted 3G Band 1 (2100MHz) when 3G is available, or over 4G VoLTE where offered. The DW200 does not boost 2G GSM voice on Band 8 (900MHz) for O2/Vodafone; if you specifically need O2/Vodafone 2G voice fallback, the Band 20+8 CG200 is the correct choice.
Does the DW200 boost 4G data for O2, Vodafone and Three?
No. The DW200 has no Band 20 (800MHz) rural 4G carrier and no Band 3-only 4G beyond the EE-family 1800MHz; O2, Vodafone and Three phones get boosted 3G Band 1 only for data and calls. If your household mainly needs O2/Vodafone 4G data in the country, the Band 20+1 CW200 or Band 20+3 CD200 is the better fit; the DW200 is purpose-built for EE-family voice+4G plus universal 3G fallback.
Expandable coverage — can I add up to 2 indoor antennas via splitter?
Expandable coverage by adding indoor antenna, splitter, cable if the outside signal is strong. When outdoor donor is strong, a 2-way passive splitter splits the indoor feed to a second whip on a far room, upstairs room or garage using extra coaxial cable, for up to 2 indoor antennas total; splitting weakens each branch, so it only helps with a strong donor, and keep outdoor-indoor separation to prevent feedback.
What upgrades are available (Yagi aerial, cable, surge protector) and how much donor is needed?
The standard kit ships a 5 dBi omni outdoor antenna on a 10m outdoor cable plus a 5m indoor cable; add the high-gain Yagi directional aerial for weak fringe signal behind hills, upgrade the outdoor cable to 20/30/40/50m for a remote roof, and add an 18KA lightning surge protector on an exposed mount. You still need at least 1–2 bars of usable outdoor Band 3/Band 1 signal at the antenna point; a booster cannot create signal where none exists.
Does the DW200 support VoLTE, and will it boost 5G? What about returns and delivery?
The DW200 boosts Band 3 EE-family voice calls and 1800MHz 4G LTE data plus Band 1 3G UMTS data/calls/SMS; calls over 4G work when the handset and network offer VoLTE. It does not boost 5G NR on any band and it does not boost Band 20 rural 4G or Band 8 2G voice. It carries a 365-day money-back guarantee with free shipping (handling 1–2 working days, UK transit 10–15 working days; return shipping deducted from refund), covering 15 European countries.
Learn More: DW200 Guides & Comparisons
Best EE Voice + 3G Signal Booster 200m² UK — 2026 Guide
How to choose a Band 3+1 booster giving EE-family voice calls, 1800 4G and all-network 3G at £205.99 for two-bed flats and small houses.
DW200 vs DW100 vs CD200 vs CW200
Honest UK comparison: Band 3+1 EE voice+4G plus all-network 3G against Band 20+3 4G-only and Band 20+1 O2/Vodafone 4G+3G at the 200m² tier.
Mobile Booster Installation Guide — 200m²
Omni/Yagi placement, 10m outdoor and 5m indoor cable routing, 2-antenna split, 20-user testing and troubleshooting for UK homes and cottages.
Band 3+1: EE Voice, 1800 4G & 2100 3G Explained
Why EE-family calls and 4G ride Band 3 (1800MHz) and all-network 3G rides Band 1 (2100MHz), and how the DW200 matrix delivers both across 200m².
Enhanced Coverage
Experience seamless connectivity with the 3G Data & Calls Mobile Signal Booster, designed to cover up to 200 square meters. Perfect for small apartments or offices, it ensures that every corner of your space receives a strong signal, eliminating dead zones.
Multi-Network Compatibility
This booster is compatible with major UK networks including EE, ASDA, and BT, making it an essential tool for households with multiple users on different carriers. Enjoy uninterrupted calls and data services regardless of your network provider.
Easy Installation
Setting up the 3G Mobile Signal Booster is a breeze. The complete kit includes all necessary components, allowing for a straightforward installation process. No technical expertise is required, so you can boost your signal in no time.
Reliable Performance
Say goodbye to dropped calls and slow data speeds. This dual-band booster enhances both 3G and voice call signals, ensuring clear communication and fast internet access. Stay connected when it matters most.
Supports Multiple Users
Designed to support up to 20 simultaneous users, this booster is ideal for families or small offices. Everyone can enjoy improved signal strength for calls, texts, and data without any interruptions.
Cost-Effective Solution
At just £205.99, the 3G Data & Calls Mobile Signal Booster offers an affordable solution to poor mobile reception. Invest in better connectivity and enhance your mobile experience without breaking the bank.
3 Steps to Full Bars
1. Place the Outdoor Antenna
Mount the antenna where you get the best signal.
2. Connect the Booster Inside
Plug in the booster and connect to the antenna.
3. Enjoy Full Bars Everywhere
Clear calls, fast data, and no more dead zones.
3G Mobile Signal Booster EE Signal Booster ASDA Mobile Booster BT Mobile Signal Enhancement Indoor Coverage Booster Dual Band Signal Booster Improve Voice Call Quality UK Mobile Network Solutions
It boost 3G and Voice Calls signal on 2100MHz, 1800MHz frequency, the frequencies used in UK by mobile networks to deliver their mobile services: 3G, 3.5G (also known as HSDPA provides faster data rates than 3G) and 2G. It can boost UK all network operators for improving 3G signal. It also can boost all networks on EE, BT, Asda, Virgin, The People's Operator, Orange, T-Mobile for improving Voice Calls & Text signal. If you have a 3G ready phone, but you’re not in a 3G area, you’ll still be able to use voice calls. Boost indoor signal cover an area up to 200 m2, is ideal for small apartments or offices.
This system is compatible with 3G and Voice Calls mobile phone networks, will provide coverage on both 1800MHz, 2100MHz frequency simultaneously. It's Dual Band booster and is an ESSENTIAL if many people in the same household are on different mobile phone networks!
Eliminates Dropped Calls
Clear Voice
No Miss Important Calls
Reliable 3G Data
Send/Receive SMS
SMS Text Messages Quickly
Faster Uploads & Downloads
Signal Wider Coverage
Reception Up to 200 sq.m.
Upgrade External Cables
If our standard package 10 meter external cable length is not enough to cover your area you have an upgrade option.
Upgrade External Aerial
Higher Gain Yagi Antenna - For better performance it's a must if indoor your phone with 1/2 signal bars. Or get this upgrade if outdoor best signal strength in the following range:2G (GSM) -76 to -90 dBm
3G (UMTS) -80 to -94 dBm
4G (LTE) -97 to -105 dBm
How to shown dBm reading on phone? Check Quick Start Guide

Upgrade Protector
Lightning Surge Protector - Designed to Protect your equipment from high amperage surges due to lightning strikes on aerials or masts in close proximity to the device. This unit is rated for 18KA of current surge and is very simple to install on any device.
Specification
| Application & Bands | [3G Data & Voice Calls] (Band 3, 1) |
| Country | United Kingdom |
| Boost All On | EE (3G & 2G) O2 (3G) Vodafone (3G) Three (3G) Asda (3G & 2G) BT (3G & 2G) Freedom Pop (3G) Giffgaff (3G) iD Mobile (3G) Lebara (3G) Lycamobile (3G) Orange (3G & 2G) Plusnet Mobile (3G) Sky Mobile (3G) Smarty Mobile (3G) Talkmobile (3G) TalkTalk (3G) Tesco (3G) The People's Operator (3G & 2G) T-Mobile (3G & 2G) Virgin (3G & 2G) |
| Users Supporting | 20 Simultaneously |
| Band | Dual Band 3 & 1 |
| Frequency | 1800MHz & 2100MHz |
| Gain(dB) | Uplink Gp≥60; Downlink Gp≥65 |
| Up-link | 1710~1785 MHz; 1930~1990 MHz |
| Down-link | 1805~1880 MHz; 2110~2180 MHz |
| Export Power(Po) | ≥10dBm |
| Power Adapter | Input: AC 100V~240V 50/60Hz; Output: DC 5V |
| What’s Included | 1 x Booster 1 x Outdoor Antenna 1 x Indoor Antenna 1 x UK Type Power Adapter 1 x 10 Meters Outdoor Cable 1 x 5 Meters Indoor Cable |
Custom your solution
Expandable coverage by adding indoor antenna if the outside signal is strong.
How It Works

1
The powerful antenna reaches out to access a voice and 3G, 4G, and LTE data signal, and delivers it to the booster
2
The booster receives the signal, amplifies it, and serves as a relay between your phone and the nearest cell tower.
3
Your devices get increased cell reception, and calls and data are fed through the booster back to the network.
Get stronger signal
Normal Cell Coverage
Dropped calls and slow data are generally caused by three things: distance from a cell tower, building materials in your home or office, or obstruction from tall objects such as trees, topography, and buildings.
Signal Coverage with our booster
Signal boosters increase cell signal by collecting signals with a powerful antenna, delivering those signals to the booster, amplifying the cell signals so your devices receive them, and delivering your device's boosted signals back to the cell tower.Installation
- Connect the indoor antenna to the MS port.
- Connect the outdoor antenna to the BS Port.
- Install the outdoor antenna and keep a minimum vertical distance of 10 meters from the indoor antenna.
- Point the outdoor antenna to the direction where you know there is possibly a higher signal strength from the base station.
- Power on the booster and check the signal strength.
- Adjust the outdoor antenna until you get the best signal strength.
IMPORTANT NOTE:
DO NOT POWER ON THE DEVICE UNTIL YOU HAVE COMPLETED THIS SETUP.
Read more about User Manual Documentation.
Application Scenarios

Home

Office

Garage

Metal Buildings
DW200 EE voice calls 4G signal booster UK Band 3 Band 1 1800 2100MHz; DW200 EE BT ASDA Virgin voice plus 1800 4G and all-network 3G booster; Band 3 1800MHz Band 1 2100MHz dual-band home repeater 200m²; £205.99 EE-family voice 4G plus 3G all-network booster 20 users UK 60/65dB 10dBm; two-bed flat small house cottage office EE calls 3G booster DW200
buy EE voice calls 4G signal booster UK two-bed flat small house; BT ASDA Virgin EE network voice plus 4G booster 200m²; O2 Vodafone Three 3G fallback booster family home EE household; EE family calls signal booster small office home office shop salon 20 users; Boost4U DW200 price £205.99 MBDW200gb; Band 3+1 Yagi weak donor cable 50m surge protector upgrade combo; rural cottage terraced home EE voice 4G 3G booster UK order; mixed-network family house EE O2 Vodafone Three 3G booster 200m²
what is a Band 3 Band 1 dual band booster for EE voice 4G and all-network 3G; why does EE voice and 4G ride Band 3 1800MHz and 3G fallback Band 1 2100MHz; how does an EE voice booster keep calls connected Ofcom licence exempt UK; how far does a 200m² booster cover vs a 100m² entry unit or larger whole-house model; do signal boosters need outside donor bars to work; what do 60dB 65dB gain and 10dBm output mean for a 200m² home repeater; omni vs Yagi directional aerial for weak rural donor UK; can I add up to 2 indoor antennas via splitter and extra cable; which networks' voice calls does a Band 3 booster actually boost
DW200 vs DW100 Band 3+1 100m² 10 users 45/50dB entry booster; DW200 vs CD200 Band 20+3 EE O2 Vodafone 4G-only booster; DW200 vs CW200 Band 20+1 O2 Vodafone 4G plus 3G booster; Band 3+1 vs Band 20+3 vs Band 20+1 which dual band should you buy; DW200 vs cheap Amazon booster that did nothing; 200m² two-bed flat vs 100m² flat vs larger whole-house booster sizing; DW200 Yagi cable surge upgrades vs standard omni 5dBi kit; EE voice booster vs O2 Vodafone voice booster which do you need UK
Why You'll Love It
Powerful Signal Boost
Easy Installation
Networks Supported
Fast Speeds
Crystal Clear Calls
Wide Coverage Area
Award-Winning Signal Booster
2026 Winner
Smart Features, Made Simple
Easy Setup
Smart Technology
Energy Efficient
Reliable Performance
24/7 Support
Secure & Safe
- Choosing a selection results in a full page refresh.
